High Performance Spunbond Polyester With PTFE Membrane For F9 Filtration Efficiency

MOQ:	10m2
Price:	USD1-20m2
Standard Packaging:	Farrleey Filtration filter material is rolled and then wrapped with a thick plastic film
Delivery Period:	14 working days
Payment Method:	L/C,D/A,D/P,T/T,Western Union
Supply Capacity:	10000m2 per month

Details Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Farrtex

Certification

ISO9001, FDA, RoHs

Model Number

MC-0130

Document

Highlight:

PTFE Membrane Spunbond Polyester

PTFE Membrane Polyester

Industrial Polyester Filter Media

Product Description

High Performance Polyester Needle Felt Fabric With PTFE Membrane For Industrial Air Purification

Farrleey Filtration Co., Ltd, located in Guangqing Industrial Park, Qingyuan, China, specializes in manufacturing advanced filtration solutions. The MC-0130 model combines polyester spunbond substrate with PTFE membrane lamination, delivering high air permeability, F9-grade filtration efficiency, and flame retardancy. Designed for demanding industrial air filtration systems, it is ideal for cleanrooms, medical equipment, painting line, surfacing treatment and more.

Key Features

Multi-Layer Composite Structure: Polyester spunbond substrate (170 g/m²) bonded with PTFE membrane, achieving F9 filtration efficiency (EN 799 compliant).
High Air Permeability: >80 mm/s airflow under 200Pa pressure (ISO 9237), minimizing system resistance.
High-Temperature Resistance: Continuous operation up to 120°C (max. 130°C, EN 1822 certified).
Robust Mechanical Strength: MD tensile strength ≥550 N/5cm, CD ≥400 N/5cm (ISO 9073), ensuring durability.
Flame Retardant: HB grade (UL94:2023), reducing fire hazards in critical environments.

Core Benefits

Superior Filtration: Captures PM2.5, dust, and microorganisms with 20% improved CADR.
Energy Efficiency: Low airflow resistance reduces fan energy consumption.
Extended Lifespan: PTFE membrane resists clogging, increasing service life by 30%.
Global Compliance: Meets ISO, EN, and UL standards for international market access.

Technical Specifications

Parameter	MC-0130 Specifications	Test Standard
Substrate Material	Polyester Spunbond	--
Weight	170 g/m²	ISO 9864
Post-Processing	PTFE Membrane + Flame Retardant	--
Thickness	0.48 mm	ISO 9073
Air Permeability	>80 mm/s (200Pa)	ISO 9237
Filtration Efficiency	F9 Grade	EN 799
Continuous Temperature	≤120°C	EN 1822
Max. Temperature	≤130°C	--
MD Tensile Strength	≥550 N/5cm	ISO 9073
CD Tensile Strength	≥400 N/5cm	ISO 9073
MD/CD Elongation	>30%	ISO 9073
Flame Retardant Grade	HB	UL94:2023

Applications

Cleanrooms: Precision environment control for electronics and pharmaceuticals.
Industrial Dust Collection: Filtration of welding fumes and powder coatings.
Medical Equipment: Ventilation systems in operating rooms and medical air filters.

Farrleey Filtration Co., Ltd is a professional manufacturer of filtration materials headquartered in Qingyuan City, Guangdong Province, China, within the Guangqing Industrial Park. Established in 2010, the company specializes in providing high-efficiency industrial filtration solutions to global customers. With advanced R&D capabilities, a stringent quality management system (ISO 9001 certified), and customized services, Farrleey has become a reliable partner in the chemical, medical, energy, and manufacturing industries.
